Materials:
- Frame – part and door part: zinc die, zinc plated
- Fastening clip and pin: steel, zinc plated.
Advantages:
- For nested door
- Hinge concealed
- RH/LH application.
- 120° opening angle
Remark:
- Fitting hardware included.
- Door thickness max 2mm when using the supplied screw
1. Cutout door
2. Cut out the frame
3. Closed
4. Opened
